Key machine in fabric finishing - heat setting gives fabric stable dimensions, hand feel and appearance.
| Model / series | ZH928-180-270 |
|---|---|
| Nominal width | 160-250cm |
| Machine speed | 5-50m/min |
| Typical running speed | 30-40m/min |
| Heat source | thermal oil 40%; natural gas 40%; steam 20% |
| Oven | Configured to customer needs |
| Fabrics | Synthetic fabrics, knits, nonwovens, coated fabrics |
| Applications | Apparel, home textiles, technical textiles |
| Function | Heat setting for stable dimensions, hand feel and appearance |
Key machine in fabric finishing - heat setting gives fabric stable dimensions, hand feel and appearance.
Published USE: key machine in fabric finishing—heat setting for stable dimensions, hand feel and appearance.
TECH fabrics: synthetic fabrics, knits, nonwovens, coated fabrics. Applications: apparel, home textiles, technical textiles.
Typical path: infeed / weft straighten → pin or clip entry → heat-set oven zones → cool → exit. For coated fabrics, the coat often sets the temperature ceiling—say so early so chambers are not oversized for the film.
Model ZH928-180-270 is the published multi-function finishing platform on a mid-width band.
Nominal width 160–250 cm; machine speed 5–50 m/min; typical running speed 30–40 m/min. Knit vs woven vs coated recipes usually sit in different parts of that band—sample before promising shift output.
Heat-source mix on TECH: thermal oil 40% / natural gas 40% / steam 20% (series tendency). Oven configured to customer needs.
Dual-purpose oven (publication CN220062464U): public text describes an oven concept aimed at handling mixed soft/hard cloth processes with shared guiding and width-adjustment ideas—useful when one line must cover knits and tighter woven or coated styles.
Tension-feedback heating roller (publication CN220750679U) and four-roller weft straightening (publication CN118029121A): support steadier tension and less skew into heat-set.
Category summary: Stenter machinery. Patent notes are technical directions only—not present legal-force claims.
This page: general finishing heat-set for apparel / home / technical fabrics; width 160–250 cm; mixed heat sources; oven configured.
Screen stenter: wider screen/mesh focus, gas heat, up to 380 cm.
Filter-cloth cylinder stenter: extra-wide filter cloth, thermal oil, no oven, slow 2–5 m/min band.
Usually a fit: synthetic, knit, nonwoven, or some coated fabrics needing dimensional memory and flat appearance; width inside 160–250 cm; willingness to lock heat source and chamber count with samples.
Usually another page: mosquito-net / industrial screen primary (stenter-01); dust-bag / liquid filter cloth primary (stenter-02); coating host without re-setting need (Coating).
Heat setting machine for polyester, nylon and other synthetic fiber screens (mosquito netting, print backing cloth, industrial filter mesh) - ensures dimensional stability, flatness and physical performance.
Specialized heat setting machine for industrial filter cloth (polyester, polypropylene, nylon) - high temperature and tension control give stable dimensions, even pores, better mechanical performance and filtration accuracy.
A: TECH on this page: model ZH928-180-270; nominal width 160–250 cm; machine speed 5–50 m/min; typical running speed 30–40 m/min; heat-source mix thermal oil 40% / natural gas 40% / steam 20%; oven configured to customer needs. Full fields are in the TECH table.
A: Fabrics: synthetic fabrics, knits, nonwovens, coated fabrics. Applications: apparel, home textiles, technical textiles—heat setting for stable dimensions, hand feel and appearance.
A: No. The published mix shows series tendency. Plant energy, fabric temperature window, and local safety rules decide the source in the proposal.
A: Public CN220062464U describes a dual-purpose oven direction for mixed soft/hard cloth processes. Related: CN220750679U (tension-feedback heating roller), CN118029121A (four-roller weft straightening). Delivered oven options follow the quotation.
A: Screen / mosquito-net / print mesh → stenter-01. Extra-wide industrial filter cloth on cylinders → stenter-02. Mixed apparel/home/technical finishing stays here.
A: Yes. Xinghua custom-builds to your process. Machines run in 20+ countries; installation, operator training, and lifetime technical support are available under contract. Call +86 510 83397635 / +86 510 83382635 or email info@xhmachinery.com.
