Foaming machine for fabric coating paste, carpet glue, decoration, faux fur, fiberglass, artificial leather backing, curtain fabric, nonwoven coating and finishing. Air-liquid and foam density semi/full automatic VFD control.
| Foaming capacity | 300-2500kg/h |
|---|---|
| Heat source | electricity |
| Oven | No oven |
| Foam output | 0.3-1.5m3/h (0.3-2t manual or full-auto PLC tracking coating speed) |
| Foaming head temperature | ≤40℃ |
| Ambient temperature | -10 to 35℃ |
| Material-air ratio | 20℃ to 80℃ (PLC set) |
| Paste viscosity | 1000-60000cps |
| Feeding | Screw pump or soft pump hose |
| Main power | 5.5KW (standard) |
| Dimensions | L 1600mm x W 650mm x H 1350mm |
| Weight | 400KG |
Foaming machine for fabric coating paste, carpet glue, decoration, faux fur, fiberglass, artificial leather backing, curtain fabric, nonwoven coating and finishing. Air-liquid and foam density semi/full automatic VFD control.
Published USE: foaming for fabric coating paste, carpet glue, decoration, faux fur, fiberglass, artificial leather backing, curtain fabric, nonwoven coating and finishing—with air-liquid and foam density semi/full automatic VFD control.
Typical path: paste/glue feed → foam head (air-liquid mix) → density control → deliver to coating or backing station. No oven on this page—it is a supply unit, not a dryer.
Foam output can track coating line speed under full-auto PLC mode (published). This is not the latex mattress complete line on other-02.
Foaming capacity 300–2500 kg/h; foam output 0.3–1.5 m³/h (0.3–2t manual or full-auto PLC tracking coating speed).
Foaming head temperature ≤40℃; ambient −10 to 35℃; heat source electricity; no oven. Live TECH also lists paste viscosity, feeding (screw pump or soft hose), main power, dimensions and weight—use the full table on the page when quoting.
Confirm paste/glue type, target foam density, whether manual or PLC tracking, and which coater or backing line the foam feeds.
No foaming-machine-specific publication number maps cleanly to this FPJ page in the verified assignee list used for the EN site. We do not invent patent numbers here.
Company-wide patents are discussed in commercial talks when relevant. Product pages only cite public texts that clearly map to that machine.
Process fit and the published TECH table are the deepen basis on this page. Category: Carpet machinery.
This page: foaming supply unit for coating paste / carpet glue and related finishes (FPJ; electricity; no oven).
Latex mattress line: complete mixing → foaming → molding → vulcanization chain—different product definition.
Pairs with carpet backing / coating hosts when foam is applied upstream of dryers—ask sales which host the foam feeds.
Usually a fit: plants that need controlled foam for fabric coating paste or carpet glue (and the other USE materials listed); willingness to lock density and PLC tracking with samples; ambient and head temp inside published bands.
Usually another page: full latex mattress production (other-02); dryer/oven design alone (carpet-05); tile cutting (carpet-11).
Production line for PVC carpet tiles - backing coating, plastication and automatic cutting for tufted or needle-punched, nylon or polypropylene carpets, producing 50x50, 50x100, 25x100, 100x100 and polygonal tiles.
Production line for bitumen / TPO carpet tiles - back coating with bitumen/TPO, backing, cooling and automatic cutting for tufted or needle-punched carpets, available in slitting or fully automatic continuous production.
A: TECH: foaming capacity 300–2500 kg/h; foam output 0.3–1.5 m³/h (0.3–2t manual or full-auto PLC tracking coating speed); foaming head temperature ≤40℃; ambient −10 to 35℃; electricity; no oven. Full fields (viscosity, pumps, power, size) are in the TECH table.
A: Fabric coating paste, carpet glue, decoration, faux fur, fiberglass, artificial leather backing, curtain fabric, nonwoven coating and finishing—with air-liquid and foam density semi/full automatic VFD control.
A: No clean foaming-machine publication is mapped on this page. We deepen with published TECH and process fit only. Ask sales if a longer company patent list is needed for a commercial discussion.
A: No. other-02 is a latex products / mattress complete line (mixing through drying). FPJ is a foaming supply unit for coating paste and carpet glue programs.
A: Paste/glue type, target foam density and output band, manual vs PLC tracking, which coater or backing line it feeds, and plant ambient. Call +86 510 83397635 / +86 510 83382635 or email info@xhmachinery.com.
A: Yes. Xinghua custom-builds to your process. Machines run in 20+ countries; installation, operator training, and lifetime technical support are available under contract.
